"DJI Agras T100"

DJI AGRAS T100

Description

The T100 Agricultural Drone, a groundbreaking creation twelve years in the making, boasts a maximum payload of 100 kg. Its operational efficiency is doubled, supporting multiple application scenarios, including spraying, spreading, and lifting tasks. Featuring industry-leading safety systems and advanced algorithms, it delivers unparalleled safety performance and an intelligent operational experience.

Key Features

• 100L Spraying Tank ,40 L/min Flow Rate

• 150 L Spreading Tank , 400 kg/min Flow Rate

• LidAR + Penta-Vision System + Millimeter-Wave Radar

• 20 m/s Max Operation Speed

• 100 kg Lifting

• Ultra-Fast Charging

Spraying System

The T100 comes equipped with a 100 L tank and dual atomizing centrifugal sprinklers, enabling faster flight speeds, wider spray coverage, and higher operation efficiency for large-scale field applications. Orchard users can choose an optional mist sprinkler set, which upgrades flow rates and atomization effects to penetrate dense canopies and reach the undersides of leaves on tall, thickly-canopied trees, ensuring outstanding versatility and performance across various agricultural tasks.

Field Operations

• 36% Increase in Operations

• 30L/min High Flow Rate

• 5-13m Effective Spray Width

• 20M/s Max Flight Speed

Duel Atomization Centrifugal Sprinkler

New flow channel design, particle size range 50-500 μm, suitable for most operational scenarios.

Magnetic Drive Impeller Pumps

Corrosion-resistant, stable, and reliable, an optimized impeller structure and increased chamber volume meet the high flow demands of orchard scenarios

Rear Four Sprinklers Array

It expands the spray width for orchard operations while maintaining uniform coverage. It also minimizes visual interference from mist, enhancing operational reliability and precision.

Dual-Channel Electromagnetic Flow Meter

Real-time precise flow detection and dynamic control ensures high-precision operations. It avoids direct contact with the liquid, preventing corrosion and enhancing durability.

Spreading System

The T100 Spreading System has been fully upgraded, with double the load capacity, and a 270% increase in flow rate. Equipped with a brand-new screw feeder, it is suitable for various granulars and can handle spreading scenarios in large fields, orchards, aquaculture, and more.

• 150 L(100kg) High Capacity Spreading Tank

• 66 % Increase in Operation Efficiency

• 400 kg/min Ultra-High Flow Rate

• 10 m Effective Spreading Width

• 20 m/s Maximum flight speed

Four Feeder Types

Supports four interchangeable feeder sizes for precise flow and greater adaptability across seeding, fertilizing, and feeding.

Small Feeder

Suitable for granulars such as rapeseed, granular herbicides, grass seeds, granular insecticides, etc. Recommended application rate: 3-22.5 kg per hectare. Recommended particle size: 0.5-4 mm.

Medium Feeder

Suitable for granulars such as rice seeds.Recommended application rate: 22.5-120 kg per hectare. Recommended particle size: 4-6 mm

Large Feeder

Suitable for granulars such as rice seeds, cover crop seeds, etc. Recommended application rate: 75-270 kg per hectare. Recommended particle size: 4-10 mm

Extra-Large Feeder

Suitable for granulars such as fertilizers, wheat seeds, granular fungicides, feed, etc. Recommended application rate: 75-750 kg per hectare. Recommended particle size: 0.5-10 mm

Safety System

T100 is equipped with advanced technologies, including a new LiDAR, millimeter-wave radar, and a Penta-Vision system. These features enable comprehensive environmental awareness, allowing for precise obstacle detection.

The system can achieve Terrain Following of slopes up to 90° without prior mapping. It also supports intelligent obstacle bypassing[2], addressing the operational requirements of most mountainous and orchard environments with efficiency and precision.

Enhanced Obstacle Avoidance Capabilities

With advanced multi-sensor fusion and upgraded algorithms, the T100 achieves a higher success rate in avoiding various obstacles. Its precision in detecting smaller obstacles is significantly improved, ensuring safer and more reliable operations.

Lift System

The T100 transforms into a transport solution. With a lifting maximum capacity of 100 kg. Features like auto balance control , weight detection, and automatic navigation to loading and unloading points make it adaptable to various agricultural transport scenarios.

Powerful Performance

• 82 kg Single-Axis Max Thrust

• 20 m/s Max Speed

• Compact Size, High Load Capacity

Energy Efficiency

• 39% Increase in Full-Load Power Efficiency

Safety Redundancy

• Propeller Stop Protection Low battery performance under heavy load

Efficient Operations

• Increase in Spray Width

• Increase in Operation Speed

• Enhanced Penetration for Orchards

62-Inch Carbon Fiber Propellers

Carbon fiber propellers offer greater rigidity and lighter weight, resisting deformation even at high temperatures. With optimized airfoil and increased diameter, efficiency is improved by 32%.

Motors and ESCs

Larger motors, more torque. 420A electronic speed controllers ensure stable and reliable operation, delivering faster response times.

DJI RC Plus Easy Control for New and Experienced Pilots

DJI RC Plus features a 7-inch high-brightness screen that is 16% brighter for clear visibility under sunlight. Both internal and external battery life are extended by 30 minutes. New backlit buttons enhance nighttime operation, and customizable physical buttons offer flexible control.

Rigorous Testing Standards

The T100 has undergone 700 hours of reliability testing, including real-flight aging, accelerated component fatigue, and extreme temperature evaluations. These ensure stability and reliability, delivering unmatched performance under various conditions.

Transmission System Seamless Signal Stability

The upgraded O4 video transmission algorithm ensures constant signal availabilitys. O4 Relay it's designed to excel in challenging signal conditions, delivering seamless and efficient operations.

Power System Ultra-Fast Charging, Energy-Efficient Design

The DB2160 Intelligent Flight Battery has an increased capacity and lighter built, offering ultra fast charging while reducing fuel consumption. Its innovative triple air-channel cooling system disperses heat through airflow, ensuring safe and stable energy management with efficient cooling even during flight.

Click Here to Watch the DJI AGRAS T100 Video

Specs

Aircraft

Weight	Weight for spraying: 75 kg (standard with 2 nozzles) Weight for spraying: 77 kg (optional with 4 nozzles) Weight for spreading: 75 kg (equipped with spreading system) Weight for lifting: 65 kg (equipped with lifting system) Weight for lifting: 90 kg (equipped with dual-battery lifting system)
Max Takeoff Weight [1	Max takeoff weight for spraying: 175 kg (standard with 2 nozzles) Max takeoff weight for spraying: 177 kg (optional with 4 nozzles) Max takeoff weight for spreading: 175 kg (equipped with spreading system) Max takeoff weight for lifting: 165 kg (equipped with lifting system) Max takeoff weight for lifting: 170 kg (equipped with dual-battery lifting system)
Max Diagonal Wheelbase	2330 mm (diagonal)
Dimensions	3220 mm × 3224 mm × 975 mm (arms and propellers unfolded) 1820 mm × 1840 mm × 975 mm (arms unfolded and propellers folded) 1105 mm × 1265 mm × 975 mm (arms and propellers folded)
Hovering Accuracy Range (with strong GNSS signal)	RTK Enabled: ±10 cm (horizontal), ±10 cm (vertical) RTK not enabled: Horizontal ±0.6 m, vertical ±0.3 m
Max Configurable Flight Radius	2 km
Operating Temperature	0 °C to 40 °C
Max Wind Resistance	<6 m/s

Motors

Stator Size	55 × 16 mm
KV	60 rpm/V

Propellers

Material	Carbon Fiber Composite
Dimensions	62 inches
Quantity	8 pairs

Spraying System

Model	LS100
Dimensions	880 mm × 870 mm × 810 mm (spray rod folded) 1020 mm × 1930 mm × 810 mm (spray rod unfolded)

Spray tank

Material	HDPE
Volume	100 L
Operating Payload	100 kg

Sprinklers

Model	LX07550SX (Standard Nozzle) / LX09550SX (Optional Mist Nozzle)
Quantity	2 (Standard) / 4 (Optional)
Nozzle Distance	1834 mm (Two Nozzles / Four Nozzles Outermost)
Droplet Size	50 – 500 μm
Effective Spray Width	5 – 13 m

Delivery Pumps

Type	Impeller Pump (Magnetic Drive)
Quantity	2
Max Flow Rate	30 L/min (Standard 2 nozzles), 40 L/min (Optional 4 nozzles)

Spreading Load

Dimensions	900 mm × 820 mm × 920 mm
Compatible Material Diameter	Standard configuration: Extra-large Screw Feeder : 0.5 mm – 10 mm granules (fertilizer, wheat, feed, etc.) Medium Screw Feeder : 4 mm – 6 mm granules (rice)
Optional:	Large Screw Feeder : 4 mm – 10 mm granules (rice, fertilizer) Small Screw Feeder : 0.5 mm – 4 mm granules (rapeseed, granular herbicides, granular insecticides)

Spreading System 4.0

Spreading Tank Volume	150 L
Spreader Structure Type	Centrifugal Disc
Discharge Structure Type	Screw Feeder Feeding
Discharge Structure Type	Screw Feeder Feeding
Max Discharge Rate	400 kg/min (compound fertilizer)
Max Load Inside the Spreading Operation Box	100 kg
Effective Spreading Width	3 – 10 m
Dimensions	Standard payload: 805 mm × 764 mm × 669 mm

Lifting System

Load Capacity	100 kg
Lifting Cable Length	10 m (standard configuration)
Recommended Cable Length	10 – 15 m
Operating Temperature	0 °C to 40 °C

Dual Battery Lifting System

Dimensions	805 mm × 960 mm × 669 mm
Load Capacity	80 kg
Lifting Cable Length	10 m (standard configuration)
Emergency Escape Mode	Cable Fuse Disconnection and Escape
Recommended Cable Length	10 – 15 m
Operating Temperature	0 °C to 40 °C

Safety System 3.0

Millimeter Wave Radar EIRP	< 20 dBm (NCC / MIC / KC / CE / FCC)
Operating Temperature	0 °C to 40 °C
Operating Environment Requirements	Adequate light and discernible surroundings
Field of View (FOV)	Laser radar: Vertical 272°, Horizontal 60° Front Radar: Horizontal 360°, Vertical ±45° Downward Radar: Left and Right ±12.5°, Front and Back ±22.5° Rear Radar: Left and Right ±45°, Front and Back ±45° Quad vision system: Horizontal 360°, Vertical 180° FPV camera: Horizontal ±86°, Vertical 108°
Measurement Range	≤ 60 m
Effective Safe Obstacle Avoidance Speed	≤ 13.8 m/s
Effective Obstacle Avoidance Height	≥ 1.5 m

Remote Controller

Model	TKPL 2
Screen	7-inch LCD touchscreen; resolution: 1920 × 1200; brightness: 1400 cd/m²
Storage Temperature Range	Less than one month: -30° to 45° C (-22° to 113° F) One to three months: -30° to 35° C (-22° to 95° F) Three months to one year: -30° to 30° C (-22° to 86° F)
Charging Temperature	5° to 40° C (41° to 104° F)
Internal Battery Runtime	3.8 hours
External Battery Runtime	3.2 hours
Charging Type	Use a USB-C fast charger with a maximum power of 65 W (maximum voltage 20 V), and it is recommended to use the DJI Portable Charger.
Charging Time	2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger

DB2160 Intelligent Flight Battery

Weight	14.7 ± 0.3 kg
Capacity	41,000 mAh
Nominal Voltage	52 V

C12000 Smart Charger

Charger Model	CSX901-12000
Dimensions	456 mm × 291 mm × 107 mm
Weight	13.13 kg
Input Voltage	Three-phase AC input: 175 – 520 V Single-phase AC input: 200 – 264 V
Output Voltage	62 V
Rated Output Current	194 A
Rated Power	12000 W (three-phase 380 V input) 3000 W (single-phase 220 V input)
Recharge Time	8 – 9 minutes (DB2160 Intelligent Flight Battery, 30% – 95% charge)
Protection Functions	Over-temperature, over-voltage, under-voltage, short circuit, fan stall, and other protection functions
Operating Temperature	0° to 40° C
Output Channels	1
Compatible with Intelligent Flight Battery	DB1580 / DB2160 Intelligent Flight Battery

Relay

Dimensions	112 mm × 112 mm × 51 mm (no antenna) 120 mm × 112 mm × 101 mm (with antenna)
Weight	630 g
Input	2.7 V – 24 V
Power Consumption	10.48 W (FCC), 8.8 W (SRRC)
Battery Capacity	6500 mAh
Operating Time	5 hours
Operating Frequency	2.4000 – 2.4835 GHz, 5.150 – 5.250 GHz, 5.725 – 5.850 GHz
Effective Signal Range	5 km (SRRC), 4 km (MIC/KCC/CE), 8 km (FCC) (In an interference-free, unobstructed environment, flight altitude 2.5 m)
Charging Time	2.5 hours (30 W recharge)
Ingress Protection Rating	IP55

D-RTK 3 AG

Supports Satellite Systems	GPS: L1/L2/L5 BeiDou: B1I/B2I/B3I/B1C/B2A/B2B Galileo: E1/E5a/E5b/E6 GLONASS: G1/G2 QZSS: L1CA/L2C/L5 L-BAND
Dimensions	345 mm × 244 mm × 300 mm
Weight	3.77 kg (including packaging)
Power Consumption	7 W
Battery Capacity	6500 mAh
Operating Frequency	Broadcast Mode: O4: 2.4G/5.8G Relay Mode: Not Supported
Effective Signal Range	FCC: 15 km SRRC: 12 km CE/JP: 8 km
Charging Time	2.5 hours (30 W recharge
Ingress Protection Rating	IP67
Positioning Accuracy	PPP Satellite-Based Service Accuracy: Convergence Time: 20 mins Horizontal: 30 cm (RMS) Elevation: 40 cm (RMS) Network RTK Calibration: Horizontal: 0.8 cm + 1 ppm (RMS) Vertical: 1.5 cm + 1 ppm (RMS) 1 ppm: Accuracy decreases by 1 mm for every 1 km increase in distance between the aircraft and the base station. For example, if the aircraft is 1 km away from the base station, the accuracy is 1.1 cm

Foot Notes

• Measured at sea level, the DJI Agriculture App will intelligently recommend the loading weight based on the current aircraft status, environmental conditions, and operational tasks. Users should not exceed the recommended maximum loading weight, as it may affect flight safety. When using in Australia, please follow local regulations and keep the maximum takeoff weight at 149.9kg.

• The effective spray width of the spraying system depends on the actual working scene

• Working height is 3 m, disc rotation speed is 1100 rpm, uniformity requirement (CV<30%) measured broadcast width is 10 m. The faster the disc rotation speed, the higher the flight altitude, the larger the broadcast width.

• Includes the weight of ropes and hooks. Measured at sea level, the DJI Agriculture App will intelligently recommend the loading weight based on the current state of the aircraft, environmental conditions, and operational tasks. The maximum weight of the loaded material should not exceed the recommended value, as it may affect flight safety.

• The effective working range of sensing distance, obstacle avoidance, and bypassing capabilities may vary due to different environmental lighting, rain, fog, and the material, location, and shape of the subject object. The downward sensing is used to assist in terrain-following altitude flight, while sensing in other directions is used for obstacle avoidance. Except for scenes without linear obstacles, if a collision occurs at speeds up to 13.8 m/s resulting in aircraft damage, responsibility can be determined through log analysis, and the aircraft may be eligible for free warranty if non-human causes are identified. If there are linear obstacles like wires or guy wires on power poles, please mark them as obstacles; otherwise, failure to bypass them will be the customer’s responsibility.

Note:1. The downward perception is used to assist terrain-following altitude flight. If a collision with an obstacle occurs below, it is considered the customer’s responsibility.2. Due to the performance limitations of the safety system, the aircraft cannot actively avoid moving objects. Accidents in such scenes are considered the customer’s responsibility.

• Sea level height, environmental temperature between 15-40 degrees Celsius, time to charge the battery from 30% to 95%; fast charging is supported when the battery cell temperature is within the range of 15-75 degrees Celsius; charging time varies depending on input power, ASL, initial charge level, and other factors.

• Positioning accuracy and reliability are affected by various factors, including equipment tilt, signal obstruction, multipath, number of satellites, geometric distribution, and atmospheric conditions. It is recommended to set up the equipment in open scenes, away from electromagnetic interference and multipath environments.
